QF10-177 · Antibacterial Inline Filter · Inline
Serie PurGuard360®
Sistema de Ducha de Mano Antibacteriano
Independently validated
ASTM F838-20 validation conducted by Vitens (NL) Laboratories.
0.08 µm
Pore size
Physical Barrier. Stops Waterborne Pathogen Larger than
0.08 microns.
Log 10
99.99999999%
Bacterial Reduction -
tested and certified to
ASTM F838-20
14,000 Liter
Service life
3,700 gallons per unit, depending on source water quality and usage conditions.
Inline
Point-of-Use
Designed for professional inline installation at showers, sinks and other fixtures.
OVERVIEW
The Inline Pureflow Blue® (Model QFI0-177) is an inline ultrafiltration system engineered to deliver high-performance bacteria reduction at the point of use, supporting water safety programs in commercial and high-risk environments. Designed to reduce waterborne bacteria including Legionella pneumophila, NTM, E. coli, Salmonella, and other bacteria, the system supports critical water safety applications across healthcare, senior living, hospitality, and commercial facilities.
Validated to achieve up to 99.99999999% (Log 10) bacteria reduction under ASTM F838-20 protocols, the system delivers consistent ultrafiltration performance under controlled operating conditions while maintaining standard water flow in professional installation applications.
Manufactured in an FDA-registered medical device establishment (Owner/Operator No. 10094411) and operating under ISO 13485:2016 quality management principles, Inline Pureflow Blue® is aligned with European water safety frameworks including DIN 58356 and DIN EN 16421.
BEST FOR
Hospitals & Medical
Centers
Ice Machines
Senior Living & Nursing Homes
Drinking Fountains
Dental Clinics
Water Treatment
Distributors
TECHNICAL SPECIFICATIONS
SPECIFICATION
DETAIL
Model
QF10-177 Inline Pureflow BLUE
Application
Inline bacterial filtration for professional plumbing installations
Material
Polypropylene (PP)
Pore size
0.08 µm Hollow Fiber Ultrafiltration Membrane
Bacterial reduction
Log 10 (99.99999999%) reduction, tested according to ASTM F838-20
Service life
3,700 gallons (14,000 liters), depending on water quality and usage conditions
Flow Performance
Maintains standard water flow with no loss in water output
Operating pressure
Continuous up to 10 bar (145 psi); short-term peak up to 20 bar (240 psi)
Operating Temperature
Continuous up to 60°C (140°F); peak up to 70°C (158°F)
Connection Type
Universal threaded connection (male × female), compatible with standard plumbing fittings
Dimensions
Width: 50mm (1.97in) · Length: 140mm (5.5in)
Weight
88g / 3.1 oz
Quality assurance
100% Membrane Integrity Tested Per Unit
Manufacturing status
Manufactured in an FDA-registered medical device establishment (Owner/Operator No. 10094411) and operating under ISO 13485:2016 quality management principles, aligned with European water safety frameworks including DIN 58356 and DIN EN 16421
DOCUMENTATION
Certifications & registrations
ASTM F838-20
Legionella pneumophila reduction to Log 10
DIN EN 16421 · DIN 58356
German / EU standards compliance
ISO 13485:2016
Quality management principles
CE Marked
EU Drinking Water Directive 2020/2184
FDA Registered — #10094411
Medical device establishment
