QF10-74 · Antibacterial Ultrafiltration System · Standalone Unit
Serie PurGuard360®
Sistema de Ducha de Mano Antibacteriano
Independently validated
ASTM F838-20 validation conducted by Vitens (NL) Laboratories.
0.08 µm
Pore size
Physical Barrier. Stops Waterborne Pathogen Larger than
0.08 microns.
Log 10
99.99999999%
Bacterial Reduction -
tested and certified to
ASTM F838-20
34,000 liter
Service life
9,000 gallons per unit, depending on source water quality and usage conditions.
Click in
Fast replacement
Filter replacement in seconds without dismantling the unit.
OVERVIEW
The AquaGuard Pro® (Model QFI0-74) is an ultrafiltration water filtration system engineered to deliver high-performance bacteria reduction, supporting water safety programs across residential, commercial, and institutional environments. Designed to reduce waterborne bacteria including Legionella pneumophila, NTM, E. coli, Salmonella, and other bacteria, the system supports critical water safety applications in hygiene-sensitive environments.
Validated to achieve up to 99.99999999% (Log 10) bacteria reduction under ASTM F838-20 protocols, the system delivers consistent ultrafiltration performance under controlled operating conditions. Its compact click-connect configuration enables rapid filter replacement without dismantling the unit, supporting long-term operational efficiency.
Manufactured in an FDA-registered medical device establishment (Owner/Operator No. 10094411) and operating under ISO 13485:2016 quality management principles, AquaGuard Pro® is aligned with European water safety frameworks including DIN 58356 and DIN EN 16421.
BEST FOR
Hospitals & Medical
Centers
Ice Machines
Senior Living & Nursing Homes
Drinking Fountains
Dental Clinics
Residential Buildings
TECHNICAL SPECIFICATIONS
SPECIFICATION
DETAIL
Model
QF10-74 AquaGuard PRO
Application
Antibacterial ultrafiltration for residential, commercial and institutional water systems
Material
Polypropylene (PP)
Pore size
0.08 µm Hollow Fiber Ultrafiltration Membrane
Bacterial reduction
Log 10 (99.99999999%) reduction, tested according to ASTM F838-20
Service life
9,000 gallons (34,000 liters), depending on water quality and usage conditions
Flow Performance
Maintains standard water flow with no loss in water output
Operating pressure
Continuous up to 10 bar (145 psi); short-term peak up to 20 bar (240 psi)
Operating Temperature
Continuous up to 60°C (140°F); peak up to 70°C (158°F)
Installation
Click-connect system — filter replacement without tools or dismantling
Dimensions
Width: 102mm (4in) · Length: 270mm (10.6in)
Weight
523g / 18.45 oz
Quality assurance
100% Membrane Integrity Tested Per Unit
Manufacturing status
Manufactured in an FDA-registered medical device establishment (Owner/Operator No. 10094411) and operating under ISO 13485:2016 quality management principles, aligned with European water safety frameworks including DIN 58356 and DIN EN 16421
DOCUMENTATION
Certifications & registrations
NSF P376
Bacteria and fungi reduction
ASTM F838-20
Legionella pneumophila reduction to Log 10
DIN EN 16421 · DIN 58356
German / EU standards compliance
ISO 13485:2016
Quality management principles
DIN EN 16421
Water system bacteria control framework
CE Marked
EU Drinking Water Directive 2020/2184
FDA Registered — #10094411
Medical device establishment
